Sony Trinitron KV-27FV310 - Page 73

— 73 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C3533 1-164-315-11 CERAMIC CHIP 470pF 5% 50V
C3534 1-109-889-11 ELECT 1µF 20% 50V
C3535 1-162-917-11 CERAMIC CHIP 15pF 5% 50V
C3536 1-126-960-11 ELECT 1µF 20% 50V
C3537 1-164-360-11 CERAMIC CHIP 0.1µF 16V
C3538 1-162-917-11 CERAMIC CHIP 15pF 5% 50V
C3539 1-162-917-11 CERAMIC CHIP 15pF 5% 50V
C3541 1-162-918-11 CERAMIC CHIP 18pF 5% 50V
C3542 1-126-964-11 ELECT 10µF 20% 50V
C3543 1-135-834-91 CERAMIC CHIP 2.2µF 6.3V
C3546 1-162-917-11 CERAMIC CHIP 15pF 5% 50V
C3547 1-126-934-11 ELECT 220µF 20% 16V
C3548 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3549 1-126-947-11 ELECT 47µF 20% 35V
C3550 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3551 1-126-947-11 ELECT 47µF 20% 35V
C3552 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3553 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3554 1-126-960-11 ELECT 1µF 20% 50V
C3555 1-126-934-11 ELECT 220µF 20% 16V
C3556 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3557 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3558 1-126-947-11 ELECT 47µF 20% 35V
C3559 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3560 1-126-947-11 ELECT 47µF 20% 35V
C3561 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3562 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3563 1-126-947-11 ELECT 47µF 20% 35V
C3564 1-126-947-11 ELECT 47µF 20% 35V
C3565 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3566 1-162-974-11 CERAMIC CHIP 0.01µF 50V
C3580 1-126-940-11 ELECT 330µF 20% 25V
C3581 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3582 1-126-934-11 ELECT 220µF 20% 16V
C3583 1-126-934-11 ELECT 220µF 20% 16V
C3585 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C3590 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
CN3500 1-764-613-11 CONNECTOR, BOARD TO BOARD 20P
DIODE
D3550 8-719-977-28 DIODE DTZ10B
FERRITE BEAD
FB3502 1-414-234-22 FERRITE 0µH
FB3503 1-414-234-22 FERRITE 0µH
FB3504 1-414-234-22 FERRITE 0µH
FB3505 1-414-234-22 FERRITE 0µH
FB3506 1-414-234-22 FERRITE 0µH
FB3507 1-414-234-22 FERRITE 0µH
FB3508 1-414-234-22 FERRITE 0µH
FB3509 1-414-234-22 FERRITE 0µH
FILTER
FL3500 1-239-848-21 FILTER, LOW PASS
FL3501 1-239-848-21 FILTER, LOW PASS
FL3502 1-239-848-21 FILTER, LOW PASS
FL3503 1-239-848-21 FILTER, LOW PASS
FL3504 1-233-736-21 FILTER, EMI
FL3505 1-233-736-21 FILTER, EMI
FL3506 1-233-736-21 FILTER, EMI
IC
IC3501 6-700-960-01 IC UPD64083GF-3BA
IC3502 8-759-462-91 IC TA1226N
IC3503 8-759-583-47 IC UPC2933T-E2
IC3504 6-700-394-01 IC BA25BC0FP-E2
IC3505 8-759-394-35 IC BA12T
CHIP CONDUCTOR
JR3301 1-216-864-11 SHORT CHIP
JR3302 1-216-864-11 SHORT CHIP
JR3501 1-216-864-11 SHORT CHIP
COIL
L3352 1-414-186-31 INDUCTOR 33µH
L3500 1-414-265-21 INDUCTOR 4.7µH
L3501 1-414-267-21 INDUCTOR 10µH
L3502 1-414-267-21 INDUCTOR 10µH
L3503 1-414-267-21 INDUCTOR 10µH
L3504 1-414-267-21 INDUCTOR 10µH
L3505 1-414-267-21 INDUCTOR 10µH
TRANSISTOR
Q3301 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3500 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3501 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3502 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
BC
