Sony Trinitron KV-27FV310 - Page 76

— 76 —
KV-27FV310/29FV310/32FV310/36FV310
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
Q3301 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3302 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3304 6-550-409-01 TRANSISTOR KSC2383-O
Q3305 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3307 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3308 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3309 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3310 8-729-422-27 TRANSISTOR 2SD601A-Q
Q3312 8-729-422-27 TRANSISTOR 2SD601A-Q
RESISTOR
R100 1-216-809-11 METAL CHIP 100 5% 1/10W
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-837-11 METAL CHIP 22K 5% 1/10W
R104 1-216-839-11 METAL CHIP 33K 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-817-11 METAL CHIP 470 5% 1/10W
R107 1-216-818-11 METAL CHIP 560 5% 1/10W
R108 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R112 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R113 1-216-845-11 METAL CHIP 100K 5% 1/10W
R114 1-216-857-11 METAL CHIP 1M 5% 1/10W
R115 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-833-11 METAL CHIP 10K 5% 1/10W
R117 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3300 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3301 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3302 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3303 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3305 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3306 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3307 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3308 1-216-837-11 METAL CHIP 22K 5% 1/10W
R3309 1-216-817-11 METAL CHIP 470 5% 1/10W
R3310 1-216-841-11 METAL CHIP 47K 5% 1/10W
R3311 1-216-819-11 METAL CHIP 680 5% 1/10W
R3312 1-216-864-11 SHORT CHIP
R3313 1-216-864-11 SHORT CHIP
R3314 1-216-864-11 SHORT CHIP
R3318 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3319 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3320 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3321 1-216-864-11 SHORT CHIP
R3323 1-249-414-11 CARBON 560 5% 1/4W
R3324 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3327 1-216-864-11 SHORT CHIP
R3328 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3329 1-216-864-11 SHORT CHIP
R3330 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3331 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3335 1-215-908-00 METAL OXIDE 33 5% 3W
R3336 1-216-809-11 METAL CHIP 100 5% 1/10W
R3343 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3346 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3347 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3348 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3350 1-216-864-11 SHORT CHIP
R3351 1-216-813-11 METAL CHIP 220 5% 1/10W
R3354 1-216-863-11 METAL CHIP 3.3M 5% 1/10W
R3359 1-216-864-11 SHORT CHIP
R3360 1-216-864-11 SHORT CHIP
R3361 1-216-864-11 SHORT CHIP
R3362 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R3363 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3364 1-247-807-31 CARBON 100 5% 1/4W
R3365 1-247-807-31 CARBON 100 5% 1/4W
R3368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3369 1-216-864-11 SHORT CHIP
R3372 1-216-864-11 SHORT CHIP
R3374 1-216-864-11 SHORT CHIP
R3390 1-216-395-00 METAL OXIDE 3.3 5% 3W
TUNER
TU150 8-598-594-30 TUNER, FSS BTF-FA421
CRYSTAL
X3301 1-781-377-21 VIBRATOR, CRYSTAL
Y
Due to the complexity of this board, performing component level fi eld repairs is
not recommended. If service is required, complete board replacement is the preferred
repair method. Data is provided for reference only.
* A-1404-854-A Y BOARD, MOUNTED
CAPACITOR
C3000 1-126-947-11 ELECT 47µF 20% 35V
C3001 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3002 1-126-947-11 ELECT 47µF 20% 35V
C3003 1-125-837-91 CERAMIC CHIP 1µF 10% 6.3V
C3004 1-126-947-11 ELECT 47µF 20% 35V
P
Y
