Sony TRINITRON KV-34DRC430 - Page 138

138
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
R3883 1-216-807-11 METAL CHIP 68 5% 1/10W
R3911 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3933 1-216-864-11 SHORT CHIP
R3937 1-216-809-11 METAL CHIP 100 5% 1/10W
R3953 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3954 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3955 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3956 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3957 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3958 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R3975 1-216-864-11 SHORT CHIP
R3976 1-216-864-11 SHORT CHIP
R3977 1-216-864-11 SHORT CHIP
R3978 1-216-864-11 SHORT CHIP
R3979 1-216-864-11 SHORT CHIP
R3980 1-216-864-11 SHORT CHIP
R3981 1-216-864-11 SHORT CHIP
R3982 1-216-864-11 SHORT CHIP
R3983 1-216-864-11 SHORT CHIP
R3984 1-218-644-11 METAL CHIP 10 0.50% 1/10W
R3985 1-218-644-11 METAL CHIP 10 0.50% 1/10W
R3986 1-218-644-11 METAL CHIP 10 0.50% 1/10W
RESISTOR BRIDGE
RB3001 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3002 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3003 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3004 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3011 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3013 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3014 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3015 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3304 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3305 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3306 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3307 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3401 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3402 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3403 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3404 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3405 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3406 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB3407 1-239-409-11 NETWORK RESISTOR(CHIP) 47
BY
RB3408 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3409 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3410 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3411 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3412 1-239-409-11 NETWORK RESISTOR(CHIP) 47
RB3421 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3422 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3423 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3424 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3425 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3426 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3427 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3428 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB3436 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB3437 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB3438 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB3439 1-234-523-21 RES, CHIP NETWORK 0 (3216)
CRYSTAL
X2801 1-760-895-21 VIBRATOR, CERAMIC
X3089 1-781-945-21 VIBRATOR, CERAMIC
X3401 1-781-887-21 VIBRATOR, CRYSTAL
HBY
* A-1302-942-A HBY BOARD, COMPLETE
CAPACITOR
C1100 1-126-960-11 ELECT 1µF 20% 50V
C1101 1-126-960-11 ELECT 1µF 20% 50V
CONNECTOR
* CN1100 1-764-334-11 PIN, CONNECTOR(PCB)(V TYPE) 11P
DIODE
D1100 8-719-977-28 DIODE DTZ10B
D1101 8-719-977-28 DIODE DTZ10B
D1103 8-719-977-28 DIODE DTZ10B
HBY
