Sony TRINITRON KV-34DRC430 - Page 139

139
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
FILTER
FL1103 1-409-755-11 FERRITE 0µH
FL1104 1-409-755-11 FERRITE 0µH
JACK
J1100 1-770-053-12 TERMINAL BLOCK, S(LIGHT ANGLE)
CHIP CONDUCTOR
JR1100 1-216-864-11 SHORT CHIP
JR1101 1-216-864-11 SHORT CHIP
JR1102 1-216-864-11 SHORT CHIP
JR1103 1-216-864-11 SHORT CHIP
JR1104 1-216-864-11 SHORT CHIP
JR1105 1-216-864-11 SHORT CHIP
JR1106 1-216-864-11 SHORT CHIP
JR1107 1-216-864-11 SHORT CHIP
RESISTOR
R1100 1-216-853-11 METAL CHIP 470K 5% 1/10W
R1101 1-216-853-11 METAL CHIP 470K 5% 1/10W
R1102 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R1103 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R1104 1-216-864-11 SHORT CHIP
R1105 1-216-864-11 SHORT CHIP
R1106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1107 1-218-665-11 METAL CHIP 75 0.50% 1/10W
R1108 1-216-864-11 SHORT CHIP
VARISTOR
VD1102 1-803-974-21 VARISTOR, CHIP (1608)
HCX
* A-1302-943-A HCX BOARD, COMPLETE
CAPACITOR
C1051 1-126-964-11 ELECT 10µF 20% 50V
CONNECTOR
* CN1052 1-564-509-11 PLUG, CONNECTOR 6P
DIODE
D1052 8-719-070-80 DIODE LNK0120022G
IC
IC1051 8-742-212-20 HYB IC SBX3081-71
RESISTOR
R1052 1-249-409-11 CARBON 220 5% 1/4W
R1054 1-249-433-11 CARBON 22K 5% 1/4W
R1055 1-249-385-11 CARBON 2.2 5% 1/4W
SWITCH
S1052 1-692-431-21 SWITCH, TACTILE
CH
* A-1400-550-A CH BOARD, MOUNTED
7-682-647-09 SCREW +PS 3X6
CAPACITOR
C9002 1-163-087-00 CERAMIC CHIP 4pF 0.25pF 50V
C9003 1-163-087-00 CERAMIC CHIP 4pF 0.25pF 50V
C9004 1-115-350-51 CERAMIC 0.0047µF 2KV
C9005 1-163-087-00 CERAMIC CHIP 4pF 0.25pF 50V
C9009 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C9010 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C9011 1-161-830-00 CERAMIC 0.0047µF 500V
C9012 1-161-830-00 CERAMIC 0.0047µF 500V
C9013 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C9014 1-161-830-00 CERAMIC 0.0047µF 500V
C9015 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C9018 1-107-961-91 ELECT 10µF 20% 250V
C9019 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C9020 1-107-961-91 ELECT 10µF 20% 250V
C9021 1-107-961-91 ELECT 10µF 20% 250V
HBY
HCX
CH
