REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
C9022 1-101-004-00 CERAMIC 0.01µF 50V
C9023 1-101-004-00 CERAMIC 0.01µF 50V
C9024 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C9025 1-104-653-11 ELECT 220µF 20% 16V
C9026 1-163-035-00 CERAMIC CHIP 0.047µF 50V
C9027 1-101-004-00 CERAMIC 0.01µF 50V
C9028 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C9029 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C9030 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C9031 1-115-350-51 CERAMIC 0.0047µF 2KV
C9032 1-162-116-00 CERAMIC 680pF 10% 2KV
C9033 1-107-662-11 ELECT 22µF 20% 350V
C9036 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C9042 1-126-940-11 ELECT 330µF 20% 25V
C9046 1-126-933-11 ELECT 100µF 20% 16V
CONNECTOR
* CN9001 1-764-334-11 PIN, CONNECTOR(PCB)(V TYPE) 11P
* CN9002 1-564-507-11 PLUG, CONNECTOR 4P
CN9003 1-695-915-11 TAB (CONTACT)
CN9004 1-695-915-11 TAB (CONTACT)
CN9009 1-785-879-11 CONNECTOR, ONE TOUCH
DIODE
D9002 8-719-977-28 DIODE DTZ10B
D9005 8-719-404-50 DIODE MA111-TX
D9006 8-719-051-85 DIODE HSS83TD
D9007 8-719-051-85 DIODE HSS83TD
D9008 8-719-051-85 DIODE HSS83TD
D9009 8-719-908-03 DIODE GP08D
D9010 8-719-110-17 DIODE RD10ESB2
IC
IC9001 8-759-360-83 IC TDA6111Q/N4
IC9002 8-759-360-83 IC TDA6111Q/N4
IC9003 8-759-360-83 IC TDA6111Q/N4
JACK
! J9001 1-451-544-11 SOCKET, CRT
COIL
L9002 1-408-591-11 INDUCTOR 1µH
L9003 1-408-591-11 INDUCTOR 1µH
L9004 1-408-591-11 INDUCTOR 1µH
L9005 1-406-666-21 INDUCTOR 150µH
L9006 1-412-525-31 INDUCTOR 10µH
TRANSISTOR
Q9001 8-729-600-22 TRANSISTOR 2SA1235-F
Q9003 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9005 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9009 8-729-600-22 TRANSISTOR 2SA1235-F
Q9010 8-729-600-22 TRANSISTOR 2SA1235-F
Q9011 8-729-600-22 TRANSISTOR 2SA1235-F
Q9014 8-729-823-81 TRANSISTOR 2SC4632LS-CB7
RESISTOR
R9001 1-216-041-00 RES-CHIP 470 5% 1/10W
R9006 1-216-073-91 RES-CHIP 10K 5% 1/10W
R9007 1-208-789-11 METAL CHIP 2K 0.50% 1/10W
R9008 1-216-085-91 RES-CHIP 33K 5% 1/10W
R9012 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9013 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9014 1-216-033-00 RES-CHIP 220 5% 1/10W
R9015 1-249-409-11 CARBON 220 5% 1/4W
R9016 1-216-033-00 RES-CHIP 220 5% 1/10W
R9018 1-216-041-00 RES-CHIP 470 5% 1/10W
R9019 1-216-041-00 RES-CHIP 470 5% 1/10W
R9026 1-208-789-11 METAL CHIP 2K 0.50% 1/10W
R9031 1-208-789-11 METAL CHIP 2K 0.50% 1/10W
R9033 1-215-447-00 METAL 12K 1% 1/4W
R9034 1-215-439-00 METAL 5.6K 1% 1/4W
R9035 1-208-790-11 METAL CHIP 2.2K 0.50% 1/10W
R9036 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9037 1-240-233-71 METAL OXIDE 100 5% 3W
R9038 1-208-790-11 METAL CHIP 2.2K 0.50% 1/10W
R9039 1-208-790-11 METAL CHIP 2.2K 0.50% 1/10W
R9041 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9042 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9043 1-240-233-71 METAL OXIDE 100 5% 3W
R9044 1-240-233-71 METAL OXIDE 100 5% 3W
R9047 1-219-744-11 METAL 220 5% 1/2W
CH
