Sony TRINITRON KV-34DRC430 - Page 141

141
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
R9048 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9049 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9050 1-249-424-11 CARBON 3.9K 5% 1/4W
R9051 1-219-744-11 METAL 220 5% 1/2W
R9052 1-219-744-11 METAL 220 5% 1/2W
R9053 1-249-424-11 CARBON 3.9K 5% 1/4W
R9054 1-249-424-11 CARBON 3.9K 5% 1/4W
R9056 1-219-743-11 METAL 100 5% 1/2W
R9057 1-219-510-11 METAL 470K 5% 1/2W
R9059 1-219-746-11 METAL 1K 5% 1/2W
R9061 1-219-743-11 METAL 100 5% 1/2W
R9062 1-260-123-11 CARBON 100K 5% 1/2W
R9063 1-216-097-11 RES-CHIP 100K 5% 1/10W
R9065 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R9068 1-216-101-00 RES-CHIP 150K 5% 1/10W
R9070 1-249-411-11 CARBON 330 5% 1/4W
R9071 1-249-411-11 CARBON 330 5% 1/4W
R9072 1-216-037-00 RES-CHIP 330 5% 1/10W
R9073 1-216-049-11 RES-CHIP 1K 5% 1/10W
R9074 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R9077 1-216-073-91 RES-CHIP 10K 5% 1/10W
R9089 1-208-806-11 METAL CHIP 10K 0.50% 1/10W
R9091 1-215-429-00 METAL 2.2K 1% 1/4W
VARIABLE RESISTOR
! RV9001 1-241-714-11 RES, ADJ, METAL FILM 110M
HAX
* A-1405-292-A HAX BOARD, MOUNTED
CONNECTOR
* CN1001 1-764-333-11 PIN, CONNECTOR(PCB)(V TYPE) 10P
* CN1002 1-564-509-11 PLUG, CONNECTOR 6P
RESISTOR
R1002 1-249-431-11 CARBON 15K 5% 1/4W
R1003 1-249-413-11 CARBON 470 5% 1/4W
R1004 1-249-415-11 CARBON 680 5% 1/4W
R1005 1-249-417-11 CARBON 1K 5% 1/4W
R1006 1-249-421-11 CARBON 2.2K 5% 1/4W
R1007 1-249-425-11 CARBON 4.7K 5% 1/4W
R1008 1-249-431-11 CARBON 15K 5% 1/4W
R1009 1-249-413-11 CARBON 470 5% 1/4W
R1010 1-249-415-11 CARBON 680 5% 1/4W
R1011 1-249-417-11 CARBON 1K 5% 1/4W
R1012 1-249-421-11 CARBON 2.2K 5% 1/4W
R1013 1-249-425-11 CARBON 4.7K 5% 1/4W
SWITCH
S1001 1-762-837-11 SWITCH, TACTILE
S1002 1-762-837-11 SWITCH, TACTILE
S1003 1-692-431-21 SWITCH, TACTILE
S1004 1-762-837-11 SWITCH, TACTILE
S1005 1-692-431-21 SWITCH, TACTILE
S1006 1-762-837-11 SWITCH, TACTILE
S1007 1-692-431-21 SWITCH, TACTILE
S1008 1-762-837-11 SWITCH, TACTILE
WY
* A-1415-602-A WY(VAR) BOARD, MOUNTED
4-382-854-01 SCREW (M3X8), P, SW (+)
CAPACITOR
C9101 1-104-999-11 MYLAR 0.1µF 5% 200V
C9104 1-126-933-11 ELECT 100µF 20% 16V
C9105 1-162-964-11 CERAMIC CHIP 0.001µF 10% 50V
C9106 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C9108 1-107-662-11 ELECT 22µF 20% 350V
C9109 1-161-830-00 CERAMIC 0.0047µF 500V
C9110 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C9111 1-126-964-11 ELECT 10µF 20% 50V
C9112 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C9113 1-137-528-11 MYLAR 0.1µF 10% 250V
C9114 1-107-636-11 ELECT 10µF 20% 160V
C9115 1-137-528-11 MYLAR 0.1µF 10% 250V
C9116 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C9117 1-117-450-11 MYLAR 0.47µF 10% 250V
C9118 1-107-826-11 CERAMIC CHIP 0.1µF 10% 16V
C9120 1-130-495-00 MYLAR 0.1µF 5% 50V
C9121 1-126-947-11 ELECT 47µF 20% 35V
C9125 1-130-495-00 MYLAR 0.1µF 5% 50V
CH
HAX
WY
