Sony TRINITRON KV-34DRC430 - Page 142

142
KV-34DRC430/36DRC430
KV-34DRC430/36DRC430
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C9126 1-126-947-11 ELECT 47µF 20% 35V
C9127 1-130-495-00 MYLAR 0.1µF 5% 50V
C9128 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C9129 1-136-177-00 FILM 1µF 5% 50V
C9144 1-162-927-11 CERAMIC CHIP 100pF 5% 50V
CONNECTOR
* CN9100 1-564-515-11 PLUG, CONNECTOR 12P
* CN9101 1-564-506-11 PLUG, CONNECTOR 3P
* CN9102 1-564-509-11 PLUG, CONNECTOR 6P
* CN9103 1-770-747-11 CONNECTOR, BOARD TO BOARD 12P
* CN9104 1-564-506-11 PLUG, CONNECTOR 3P
FERRITE BEAD
FB9100 1-410-397-21 FERRITE 1.1µH
FB9101 1-410-397-21 FERRITE 1.1µH
IC
IC9100 8-759-822-38 IC LA6510
COIL
L9100 1-412-525-31 INDUCTOR 10µH
TRANSISTOR
Q9100 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9102 8-729-600-22 TRANSISTOR 2SA1235-F
Q9103 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9104 8-729-600-22 TRANSISTOR 2SA1235-F
Q9105 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9106 8-729-600-22 TRANSISTOR 2SA1235-F
Q9107 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9108 8-729-600-22 TRANSISTOR 2SA1235-F
Q9109 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9110 8-729-045-04 TRANSISTOR 2SC5511
Q9111 8-729-045-05 TRANSISTOR 2SA2005
Q9121 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9122 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q9123 8-729-600-22 TRANSISTOR 2SA1235-F
Q9124 8-729-600-22 TRANSISTOR 2SA1235-F
RESISTOR
R9101 1-216-805-11 METAL CHIP 47 5% 1/10W
R9102 1-260-322-11 CARBON 330 5% 1/2W
R9103 1-216-819-11 METAL CHIP 680 5% 1/10W
R9104 1-216-820-11 METAL CHIP 820 5% 1/10W
R9105 1-216-837-11 METAL CHIP 22K 5% 1/10W
R9106 1-218-715-11 METAL CHIP 9.1K 0.50% 1/10W
R9107 1-216-809-11 METAL CHIP 100 5% 1/10W
R9108 1-216-817-11 METAL CHIP 470 5% 1/10W
R9109 1-216-817-11 METAL CHIP 470 5% 1/10W
R9110 1-216-805-11 METAL CHIP 47 5% 1/10W
R9111 1-216-805-11 METAL CHIP 47 5% 1/10W
R9112 1-249-389-11 CARBON 4.7 5% 1/4W
R9113 1-249-389-11 CARBON 4.7 5% 1/4W
R9114 1-249-389-11 CARBON 4.7 5% 1/4W
R9115 1-249-389-11 CARBON 4.7 5% 1/4W
R9116 1-249-389-11 CARBON 4.7 5% 1/4W
R9117 1-249-389-11 CARBON 4.7 5% 1/4W
R9118 1-249-389-11 CARBON 4.7 5% 1/4W
R9119 1-249-389-11 CARBON 4.7 5% 1/4W
R9120 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R9121 1-216-848-11 METAL CHIP 180K 5% 1/10W
R9122 1-216-847-11 METAL CHIP 150K 5% 1/10W
R9123 1-216-848-11 METAL CHIP 180K 5% 1/10W
R9124 1-216-847-11 METAL CHIP 150K 5% 1/10W
R9125 1-218-867-11 METAL CHIP 6.8K 0.50% 1/10W
R9126 1-216-805-11 METAL CHIP 47 5% 1/10W
R9127 1-216-805-11 METAL CHIP 47 5% 1/10W
R9128 1-215-888-00 METAL OXIDE 220 5% 2W
R9130 1-218-700-11 METAL CHIP 2.2K 0.50% 1/10W
R9131 1-218-730-11 METAL CHIP 39K 0.50% 1/10W
R9132 1-218-713-11 METAL CHIP 7.5K 0.50% 1/10W
R9133 1-249-391-11 CARBON 6.8 5% 1/4W
R9134 1-249-383-11 CARBON 1.5 5% 1/4W
R9135 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R9138 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
R9139 1-218-692-11 METAL CHIP 1K 0.50% 1/10W
R9140 1-216-864-11 SHORT CHIP
R9141 1-214-657-11 METAL 1 1% 1/4W
R9142 1-214-657-11 METAL 1 1% 1/4W
R9143 1-216-429-00 METAL OXIDE 270 5% 1W
R9144 1-215-867-00 METAL OXIDE 470 5% 1W
R9145 1-218-712-11 METAL CHIP 6.8K 0.50% 1/10W
