KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
6-4(4). SUB COLOR ADJUSTMENT (PAL RF MODE)
Input signal : PAL Color bar (100%)
Picture : HI-FINE mode
Condition : SAJ 00 PIC 3F
SAJ 02 COL 1F
SAJ 0E CLO 04
SAJ 10 HUO 05
JGL 01 RGB 07
Adjusting parameter:
YCT 03 SCL
6-5. DEFLECTION ADJUSTMENTS
FOR DRC 1250 (50Hz) MODE
1. Set to Service Mode.
2. Input a PAL cross hatch/dot signal.
3. Set the following condition.
Picture Mode to [DYNAMIC], Picture Rotation to [+/–0] and
Eco Mode to OFF.
4. Set to DRC-MF1250 mode.
5. Using the [1] and [4] button, select category GEO (Service
Mode).
6. Select and adjust the following items to obtain optimum
image. Raise/lower the data using the [3] and [6] buttons.
Service Item
GEO : 00 VSZ V SIZE
01 VPS V POSITION
02 VLN V LINEARITY
03 SCO S CORRECTION
04 HSZ H SIZE
06 PAP PIN AMP
07 UPN UPPER CORNER PIN
08 LPN LOWER CORNER PIN
CORRECTION POSITION
SETTING
09 UCG MOST UPPER CORNER
PIN ADJUSTMENT
0E PPH V TRAPEZOID ADJUSTMENT
0F AGL AFC ANGLE
10 BOW AFC BOW
11 HTR V SAW0 WAVE SAW LEVEL
GAIN CONTROL
12 MPD MP PARA WAVE DC BIAS
CONTROL
14 PBP H CENT PARA WAVE SAW
LEVEL GAIN CONTROL
15 PBA H CENT PARA WAVE GAIN
CONTROL
DAC : 00 HCT H CENTER
01 HLN H LINEARITY
7. Write into the memory by pressing [MUTING] then [0] on
the remote commander.
FOR WIDE MODE, DRC1250 (50Hz)
8. Adjust condition change to WIDE MODE : ON.
9. COPY (item FOR DRC 1250 (50Hz) MODE and adjust
data for the following items.
Service Item
GEO : 00 VSZ V SIZE
01 VPS V POSITION
04 HSZ H SIZE
12 MPD MP PARA WAVE DC BIAS
CONTROL
14 PBP H CENT PARA WAVE SAW
LEVEL GAIN CONTROL
10. Adjust V Blanking the following items.
Service Item
GEO : 1E VAS V ASPECT
1F VSC V SCROLL
FOR DRC 1250 (60Hz) MODE
11. Input 525/60Hz signal.
12. Set to DRC-MF : 1250
13. COPY (item for DRC 1250 (50Hz) mode and adjust data
for the following items.
Service Item
GEO : 12 MDP MP PARA WAVE DC BIAS
CONTROL
14 PBP H CENT PARA WAVE SAW
LEVEL GAIN CONTROL
14. Adjust the following items.
Service Item
GEO : 00 VSZ V SIZE
01 VPS V POSITION
02 VLN V LINEARITY
03 SCO S CORRECTION
04 HSZ H SIZE
05 HPS H POSITION
06 PAP PIN AMP
07 UPN UPPER CORNER PIN
08 LPN LOWER CORNER PIN
09 UCG MOST UPPER CORNER
PIN ADJUSTMENT
0E PPH V TRAPEZOID ADJUSTMENT
0F AGL AFC ANGLE
10 BOW AFC BOW
11 HTR V SAWO WAVE SAW LEVEL
GAIN CONTROL
15 PBA H CENT PARA WAVE GAIN
CONTROL
DAC 01 HLN H LINEARITY
