Sony TRINITRON KV-DR29M39 - 9 Electrical Parts List

– 113 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
* A-1300-392-A A BOARD COMPLETE (KV-DR29M39)
* A-1300-386-A A BOARD COMPLETE (KV-DR29M63)
* A-1300-513-A A BOARD COMPLETE (KV-DR29M69)
* A-1300-404-A A BOARD COMPLETE (KV-DR29M89)
*********************************
4-382-854-11 SCREW (M3X10), P, SW (+)
<CAPACITOR>
C001 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C002 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C004 1-163-001-11 CERAMIC CHIP 220PF 10.00% 50V
C005 1-163-001-11 CERAMIC CHIP 220PF 10.00% 50V
C006 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C007 1-126-933-11 ELECT 100UF 20.00% 16V
C009 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C010 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C012 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C013 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C014 1-126-967-11 ELECT 47UF 20.00% 50V
C015 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C016 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C017 1-163-247-91 CERAMIC CHIP 68PF 5.00% 50V
C020 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C021 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C022 1-163-809-11 CERAMIC CHIP 0.047UF 10.00% 25V
C024 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C028 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C030 1-126-947-11 ELECT 47UF 20.00% 25V
C031 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C032 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C033 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C034 1-163-259-91 CERAMIC CHIP 220PF 5.00% 50V
C035 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C036 1-104-665-11 ELECT 100UF 20.00% 25V
C041 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C043 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C044 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C045 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C046 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C047 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C048 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C050 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C052 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C053 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C103 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C104 1-126-933-11 ELECT 100UF 20.00% 16V
C107 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C108 1-126-933-11 ELECT 100UF 20.00% 16V
C109 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C110 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C111 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
C112 1-126-933-11 ELECT 100UF 20.00% 16V
C113 1-126-967-11 ELECT 47UF 20.00% 50V
C114 1-126-967-11 ELECT 47UF 20.00% 50V
C301 1-126-768-11 ELECT 2200UF 20.00% 16V
C326 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1100 1-163-239-11 CERAMIC CHIP 33PF 5.00% 50V
C1101 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C1102 1-163-007-11 CERAMIC CHIP 680PF 10.00% 50V
C1200 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C1201 1-216-025-11 RES-CHIP 100 5% 1/10W
C1202 1-126-947-11 ELECT 47UF 20.00% 16V
C1203 1-126-947-11 ELECT 47UF 20.00% 16V
C1204 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C1205 1-107-698-11 ELECT 10UF 20.00% 25V
C1206 1-216-025-11 RES-CHIP 100 5% 1/10W
C1207 1-107-698-11 ELECT 10UF 20.00% 25V
C1208 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C1209 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C1210 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C1211 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C1215 1-126-960-11 ELECT 1UF 20.00% 50V
C1216 1-126-964-11 ELECT 10UF 20.00% 50V
C1217 1-104-665-11 ELECT 100UF 20.00% 25V
C1220 1-126-960-11 ELECT 1UF 20.00% 50V
C1222 1-110-501-11 CERAMIC CHIP 0.33UF 10.00% 16V
C1223 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1224 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1225 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1226 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1227 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1228 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1229 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1230 1-126-963-11 ELECT 4.7UF 20.00% 50V
C1232 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C1233 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C1234 1-126-974-11 ELECT 3300UF 20.00% 50V
C1235 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C1236 1-163-009-91 CERAMIC CHIP 0.001UF 10.00% 50V
C1237 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C1238 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C1239 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1241 1-128-550-11 ELECT 2200UF 20.00% 50V
C1243 1-126-974-11 ELECT 3300UF 20.00% 50V
C1244 1-128-550-11 ELECT 2200UF 20.00% 50V
C1245 1-128-550-11 ELECT 2200UF 20.00% 50V
C1247 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1248 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C1249 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C1250 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1251 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
• Items marked " ∗ " are not stocked since
they are seldom required for routine
service. Some delay should be antici-
pated when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : mH, UH : µH
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
A
