– 112 –
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
REF. NO. PART NO. DESCRIPTION REMARK
151 X-4040-251-1 CABINET ASSY 152-154,172-175
(KV-DR29M39/DR29M69)
X-4040-194-1 CABINET ASSY (KV-DR29M63)
X-4040-190-1 CABINET ASSY (KV-DR29M89)
152 * 4-036-405-11 SPRING, COMPRESSION
(KV-DR29M39/DR29M69/DR29M89)
* 4-036-405-21 SPRING, COMPRESSION (KV-DR29M63)
153 * 4-086-448-01 BUTTON, POWER
(KV-DR29M39/DR29M69/DR29M89)
* 4-088-316-01 BUTTON, POWER (KV-DR29M63)
154 4-086-707-01 GUIDE, LIGHT
155 ! 8-735-056-05 PICTURE TUBE (M68LNH070X) (KV-DR29M63)
! 8-735-057-05 PICTURE TUBE (M68LNH070X)
(KV-DR29M39/DR29M69/DR29M89)
156 * 3-704-372-11 HOLDER, HV CABLE (KV-DR29M39)
157 4-046-600-11 SPACER, DY
(KV-DR29M39/DR29M69/DR29M89)
4-064-818-01 SPACER, DY (KV-DR29M63)
158 X-4387-214-3 PERMALOY ASSY, CORRECTION
(KV-DR29M39/DR29M69/DR29M89)
4-051-734-42 PIECE B (120) CONV CORRECT (KV-DR29M63)
159 ! 8-451-504-61 DEFLECTION YOKE (Y29RSC-S2)
160 * A-1400-488-A C BOARD, MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
* A-1400-690-A C BOARD, MOUNTED (KV-DR29M63)
161 ! 1-419-323-21 COIL, DEGAUSSING (KV-DR29M39)
! 1-419-323-31 COIL, DEGAUSSING (KV-DR29M63)
! 1-419-294-21 COIL, DEGAUSSING (KV-DR29M69/DR29M89)
REF. NO. PART NO. DESCRIPTION REMARK
162 * 4-063-935-21 CUSHION (50 x 550), DGC
163 4-064-883-03 HOLDER, DGC
164 1-452-896-11 COIL, NA ROTATION (RT200)
(KV-DR29M39/DR29M69/DR29M89)
1-452-896-91 COIL, NA ROTATION (KV-DR29M63)
165 * A-1400-499-A VM BOARD, MOUNTED
(KV-DR29M39/DR29M69/DR29M89)
* A-1400-694-A VM BOARD, MOUNTED (KV-DR29M63)
166 4-369-318-61 SPRING, TENSION
(KV-DR29M39/DR29M69/DR29M89)
4-369-318-41 SPRING, TENSION (KV-DR29M63)
167 1-452-032-00 MAGNET, DISC
168 1-452-094-00 CIRCULAR DISC MAGNET B
169 4-077-228-02 PIECE, TLH CONVERGENCE
170 4-079-376-01 BAND, DGC
- QUANTITY 2 (TOP(1), BOTTOM (1))
(KV-DR29M39 ONLY)
- QUANTITY 1 (TOP(1) ONLY)
(EXCEPT KV-DR29M39)
171 8-453-011-41 NA299-C
172 X-4039-978-1 DOOR ASSY CONTROL
(KV-DR29M39/DR29M69/DR29M89)
X-4040-195-1 DOOR ASSY CONTROL (KV-DR29M63)
173 4-079-175-01 SCREW, CRT (TAPPING 7+M8)
174 4-083-848-02 DAMPER DOOR
175 X-4039-976-1 BEZEL ASSY ( p 18 SCREWS)
176 4-387-204-01 NUT, SPECIAL CRT
177 4-069-652-02 CUSHION (HS BAND)
(KV-DR29M39/DR29M69/DR29M89)
4-069-652-11 CUSHION (HS BAND) (KV-DR29M63)
178 * 4-062-970-12 CLIP (29RSN), DGC
