– 114 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
C1252 1-163-037-11 CERAMIC CHIP 0.022UF 10.00% 50V
C1253 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1254 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C1255 1-126-941-11 ELECT 470UF 20.00% 25V
C1256 1-126-964-11 ELECT 10UF 20.00% 50V
C1257 1-126-933-11 ELECT 100UF 20.00% 16V
C1258 1-126-960-11 ELECT 1UF 20.00% 50V
C1259 1-126-964-11 ELECT 10UF 20.00% 50V
C1261 1-126-960-11 ELECT 1UF 20.00% 50V
C1262 1-126-957-11 ELECT 0.22UF 20.00% 50V
C1263 1-126-965-91 ELECT 22UF 20.00% 50V
C1264 1-126-965-91 ELECT 22UF 20.00% 50V
C1265 1-249-429-11 CARBON 10K 5% 1/4W
C1266 1-126-960-11 ELECT 1UF 20.00% 50V
C1267 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1268 1-163-018-00 CERAMIC CHIP 0.0056UF 10.00% 50V
C1270 1-163-018-00 CERAMIC CHIP 0.0056UF 10.00% 50V
C1271 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1273 1-126-964-11 ELECT 10UF 20.00% 50V
C1274 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1275 1-126-948-11 ELECT 100UF 20.00% 35V
C1276 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C1277 1-104-760-11 CERAMIC CHIP 0.047UF 10.00% 50V
C1279 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C1280 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C1281 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C1282 1-164-489-11 CERAMIC CHIP 0.22UF 10.00% 16V
C1283 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C1284 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C1285 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C1286 1-164-182-11 CERAMIC CHIP 0.0033UF 10.00% 50V
C1287 1-164-182-11 CERAMIC CHIP 0.0033UF 10.00% 50V
C1288 1-163-989-11 CERAMIC CHIP 0.033UF 10.00% 25V
C1289 1-163-989-11 CERAMIC CHIP 0.033UF 10.00% 25V
C1291 1-104-665-11 ELECT 100UF 20.00% 25V
C1292 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1293 1-163-019-00 CERAMIC CHIP 0.0068UF 10.00% 50V
C1295 1-126-964-11 ELECT 10UF 20.00% 50V
C1296 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C1297 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1298 1-126-960-11 ELECT 1UF 20.00% 50V
C1301 1-126-933-11 ELECT 100UF 20.00% 16V
(KV-DR29M39/M69/M89)
C1302 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
(KV-DR29M39/M69/M89)
C1312 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C1322 1-137-374-11 MYLAR 0.047UF 5.00% 50V
C1323 1-136-165-00 FILM 0.1UF 5.00% 50V
C2200 1-126-964-11 ELECT 10UF 20.00% 50V
C2201 1-126-964-11 ELECT 10UF 20.00% 50V
C2202 1-126-964-11 ELECT 10UF 20.00% 50V
C2203 1-126-963-11 ELECT 4.7UF 20.00% 50V
C2204 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C2205 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C2206 1-126-964-11 ELECT 10UF 20.00% 50V
C2207 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C2208 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C2209 1-126-968-11 ELECT 100UF 20.00% 50V
C2600 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2601 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2602 1-126-933-11 ELECT 100UF 20.00% 16V
C2603 1-126-933-11 ELECT 100UF 20.00% 16V
C2605 1-104-665-11 ELECT 100UF 20.00% 10V
C2606 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2607 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2609 1-104-665-11 ELECT 100UF 20.00% 10V
C2612 1-104-665-11 ELECT 100UF 20.00% 25V
C2613 1-126-936-11 ELECT 3300UF 20.00% 16V
C2615 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C2616 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3001 1-126-963-11 ELECT 4.7UF 20.00% 50V
C3002 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C3003 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C3005 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C3006 1-126-964-11 ELECT 10UF 20.00% 50V
C3007 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C3008 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C3010 1-126-947-11 ELECT 47UF 20.00% 16V
C3012 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C3013 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3015 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
C3019 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C3020 1-109-982-11 CERAMIC CHIP 1UF 10.00% 10V
C3021 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V
C3033 1-126-947-11 ELECT 47UF 20.00% 16V
C3034 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C3037 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3038 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3039 1-216-295-91 SHORT CHIP 0
C3040 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3041 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C3042 1-126-947-11 ELECT 47UF 20.00% 16V
C3043 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3044 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3045 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3046 1-117-720-11 CERAMIC CHIP 4.7UF 10V
C3330 1-107-725-11 CERAMIC CHIP 0.1UF 10.00% 16V
(KV-DR29M39/M69/M89)
C3331 1-126-933-11 ELECT 100UF 20.00% 16V
(KV-DR29M39/M69/M89)
C3336 1-126-933-11 ELECT 100UF 20.00% 16V
(KV-DR29M39/M69/M89)
C3338 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
(KV-DR29M39/M69/M89)
C3350 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
(KV-DR29M39/M69/M89)
C3351 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
(KV-DR29M39/M69/M89)
C3352 1-163-005-91 CERAMIC CHIP 470PF 10.00% 50V
(KV-DR29M39/M69/M89)
C3353 1-126-933-11 ELECT 100UF 20.00% 16V
(KV-DR29M39/M69/M89)
C3354 1-126-967-11 ELECT 47UF 20.00% 50V
(KV-DR29M39/M69/M89)
C3355 1-126-967-11 ELECT 47UF 20.00% 50V
(KV-DR29M39/M69/M89)
C4301 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4302 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4303 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4304 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4305 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4306 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C4307 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C4308 1-164-492-11 CERAMIC CHIP 0.15UF 10.00% 16V
A
