Sony TRINITRON KV-DR29M39 - Page 77

– 91 –
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
Ref Pin No. Voltage[v]
53.6Vp-p
NTSC3.58
4
2.7Vp-p
PA L
4
1.8Vp-p
5
260Vp-p
6
370Vp-p
7
2.3Vp-p
8
8.8Vp-p
9
Ref Pin No. Voltage[v]
2.2Vp-p
NTSC3.58
10
7.6Vp-p
PA L
10
9.2Vp-p
11
8.9Vp-p
12
2.6Vp-p
NTSC3.58
13
7.8Vp-p
PA L
13
D BOARD VOLTAGE LIST AND WAVEFORM
