– 106 –
KV-DR29M39/DR29M63/
KV-DR29M69/DR29M89
RM-991
SDA9588XB23
TLC2933IPWR-12
TC7SET08FU(TE85R)
TLC2932IPWR
CXA1875AM-T4
UPC4558G2
NJM4560M
MM1115XFBE
M52055FP
MSM514265E-
60JSDR1
TC90A69F
BU4053BCF-E2
M24C16-MN6T(A)
LA6510 CXD2095AQ
UPD64083
CXP750096-044Q
MT48LC1M16A1TG65 PQ07VZ012ZP
MM1476AF(TP) S-80743AL-A7-T1 AN7583Z PQ05RF2
CXA2151Q
TC90A90F
CXA2150Q
CXA2069Q
CXA2163AQ
NJM78L05A
TRANSISTOR
2SA2005
2SC5511
IRF1830G-LF49
2SC3840(3)
2SC2785-HFE
2SA1175-HFE
DTC114ESA
DTC144ESA
2SD2114K
2SC2712-YG
UN2213
2SA1037AK-T146-R
MSB709-RT1
2SA1162-G
UN2211
DTC114TKA-T146
DTC144EKA
2SC2223-F13
2SD601A-Q-TX
DTC114EKA-T146
MSD601-RT1
2SC1623-L5L6
IRF1B7N50A-LF31
2SC2500-B
BR24C16F-E2 BA25BC0FP-E2
BA033FP-E2
Small outline L-leaded
Pin 8 ~ 98
1
TOP VIEW
SOP
TOP VIEW
TOP VIEW
E
B
C
E
B
C
IRF1740G
NJM2870F33-TE2
IC
SBX1981-51P
UPC1093J-1-T
NJM79L12A-T1
B
C
E
