Sound Devices 833 User Guide

833 User Guide
52
USB-A
USB-A allows multiple devices to be used to control and monitor vari-
ous functions of the 833. Should multiple devices be used simultane-
ously, the use of a USB-A type hub is required.
USB-C
USB-C allows for high-speed le transfer between a computer and any
of the 833’s media.
Note: All other functionality is suspended in USB File Transfer mode.
2-In 2-Out USB audio is available via the USB-C port on the 833. All
routing is handled through the channel and output routing matrices.
No special drivers are needed as the built-in OS drivers will work
properly.
Windows OS users - 96kHz max sample rate, MacOS users - 192kHz
max sample rate.
USB Audio is supported for Windows 10 and above.

Sound Devices 833 Specifications

General

Number of Channels	8
Mic Inputs	6
Main Outputs	2
Aux Outputs	4
Headphone Output	1
Bit Depth	24-bit
Timecode	Yes
Dynamic Range	120 dB
Microphone Preamps	6
Analog Outputs	4
Type	Portable Mixer-Recorder
Line Inputs	6
AES Inputs	2
Sampling Rate	up to 192 kHz
Recording Media	SD, SDHC, SDXC
Power	Battery or External DC
Frequency Response	10 Hz to 80 kHz
THD+N	0.005%
Digital Outputs	2
