Spartan 1065 - Page 29

Page 29
1065 Frame Assembly
44118500
ITEM QTY PART NUMBER DESCRIPTION
1 1 02750200 Washers, Zn. Plated
2 1 02822300 Thumb Screw, 3/8-16
PARTS REQUIRED TO SECURE DRUM
ITEM QTY PART # DESCRIPTION
1 1 04204700 Lower Casting Assy 1065
2 1 04205400 Back Casting Assy 1065
4 1 03414700 Upper Front Casting Assy
5 1 04204400 Thumb Screw Assy M
6 2 02897800 Rubber Tired Wheel 8 X 2.50
7 2 44302400 Screw,Hex Hd Cap 5/8-18x3-1/2
9 1 44291100 Ass'y, Pm Motor Support 1065
10 2 02820800 Nut, Hex Jam 5/8-18
11 2 00167600 5/8 Lockwasher
12 2 02853800 Thumb Screw 3/8" -16 X 1-1/2"
16 2 04205500 Crawler Tread Assy Universal
20 2 00116000 Screw,Hex Hd Cap 3/8-16 X 1/2
21 2 00140000 Square Nut 3/8-16 Zinc Pltd
22 1 02818200 Handle-1" Od X 16 Ga. Welded
23 1 02769100 Thrust Bearing 621
24 1 04205300 Tangent Lock Assy.
26 1 03426500 Ass'y, Handle & Screw
33 2 02824000 Phillips Fillister Hd Mach.
36 1 44281400 Decal,1065,300,2001 Safety
