Spartan 1065 - 44219900 Bearing Block Assy (Short)

Page 50
ITEM Q TY
PART
NUMBER DESCRIPTION
29 1 04217800 Block Bearing Short Mod 75 Feed
31 4 00113901 Screw, Hex Hd 1/4-20 x 1
33 2 04219600 Thrust Race
34 1 04219500 Thrust Bearing
35 1 44222100 2001 Knob
36 1 44213800 Dial A Cable Block
37 1 44222200 Roll Pin 2001
FIG 8 1 44119700 Wheel Carrier Body Comp (Short)
44219900
Bearing Block Assy (Short)
Fig. 7
33
36
35
37
FIG 8Reference:
29
34
33
31
