1065 Drum Assembly
44063100
15
2
A
A
7
54
3
12
Section A-A
ITEM QTY PART NUMBER DESCRIPTION
2 1 04205200 Outer Drum Hub Assy 1065
3 1 04205100 External Drum Assy 1065
4 12 02825000 Int/Ext Tooth Lockwasher
5 12 00114800 Screw,Hex Hd Cap 5/16-18 X 5/8
7 1 04717700 Decal, Model 1065
10 2 00165800 Washer Lock-Split Medium 3/8
11 2 02934100 3/8-16 Hex Nut Zinc Pltd
12 1 02756900 Internal Drum Assembly-1065
14 1 44110600 1065 Cable Clamp Assy.
15 1 02761200 Decal, Spartan Warning
14
10
10
11
11
