Operating Instructions For
Model 75 Dial-A-Cable Power Feed
(See: Fig. 4, Fig. 5, Fig. 6 & Fig. 8)
Follow all safety instructions as outlined in your operator’s manual supplied
with your machine. If a new operator manual is required, contact Spartan
Tool (800-435-3866) or download it at www.spartantool.com.
The following instructions refer to the use of the Spartan cable safety guide (44225300) (Fig. 1)
which we recommend for safer operation. Always wear Spartan riveted gloves when operating
machines.
Upon completion of installation instructions for your machine and before actual sewer cleaning, it is
recommended you become familiar with your power feed operation. By moving the actuator assembly
(#12) by use of the knob (#1) you will note the wheel carrier blocks (#21) and (#32) will turn. When
the drum and cable are rotating the movement will feed the cable in and out by the slanting of the
drive bearings (#26). The decal (#4) on the front bearing plate (#5) is marked from left to right “R”
(reverse), “N” (neutral), and “F” (forward).
1. Place the actuator handle to the midway point between “N” and “F” on the name plate.
2. No cutter should be attached to the cable at this time.
3. The forward/reverse electrical switch should be placed in the forward “F” with the machine plugged
in to a power supply. Note: If drum rotation is reversed, feed of cable will be reversed.
4. Momentarily step on foot switch and check machine rotation. Drum and cable should rotate left
or counter clockwise from cable end of machine.
Use care when performing the next operation as cable will be fed out and if
allowed to feed too long may whip. Do not feed cable out more than 12
inches from feed unit.
5. With left hand on actuator assembly knob and right hand on adjusting knob #18, step on footswitch
and slowly tighten (turn clockwise) knob #18. When cable is driving steadily forward, stop turning
knob. Move actuator assembly knob to “R” position on name plate and cable should now retrieve.
Cable movement will stop feeding in or out when actuator assembly knob is placed in the “N”
position. You will note the farther the actuator assembly knob is moved to the forward or reverse
position, the faster the cable will move out or in.
WARNING!
WARNING!
