Spartan 1065 - Universal Anchor Assy; Air Foot Switch

Page 37
.66 Universal Anchor Assembly
44292400
4
1
2
3
ITEM QTY PART NUMBER DESCRIPTION
1 1 02821800 Expansion Pin 3/4" Cable
2 1 44120500 .66 Female Coupling
3 1 44117400 Roll Pin Carbon Steel
4 1 44291501 Ass'y,Adapter, Anchor .66-3/4
Item No Part No Req'd Description
44055500 1 Air Foot Switch (Complete As Shown)
1 04576900 1 Pressure Transmitter
2 04577100 1 Air Hose
3 04652700 2 Crimp Type Hose Clamp
Air Foot Switch - 44225800
