Spartan 1065 - 04221000 Universal Power Feed

Page 47
04221000
Model 75 Universal Power Feed
ITEM QTY
PART
NUMBER DESCRIPTION
11 1 03409000 Bushing Lock
39 2 00113600 Screw, Hex Hd 1/4-20 x 3/4
40 2 00162400 Washer, Flat 3/16 USS
41 2 00167000 Lockwasher, Internal Tooth
FIG 4 1 04217500 Power Feed Model 75
Fig. 14
(Universal Unit Fits 100-200-300-1065 Machines)
FIG 4
Reference:
11
41
40
39
Item # 11
For use with
model 300 only
