Page 54
Installation Instructions
For Model 100
(See: Fig. 4 and Fig. 5)
The following instructions are for manual machines, delete step 1 through 3 when replacing older
power feed units.
1. Remove mounting plate (#16) from Dial-A-Cable power feed and reposition bolts in upper holes
in (#16) plate.
2. Remove thumb screws and latch assembly from trunnion on machine.
3. Position drum into place on power drive unit.
4. Set Dial-A-Cable adjusters for 3/4” cable size (full open) and turn knob (#18) counter clockwise
(left) to raise upper wheel carrier. Place actuator handle (#12) to “N” neutral position.
5. Slide Dial-A-Cable power feed unit over cable end. Position mounting plate on trunnion using
the two (2) round holes and locking in place with the two (2) thumb screws removed in step 2.
Tighten securely.
6. Position the cable forward to the point where the smallest diameter of cable will come in contact
with the drive bearings, adjust your Dial-A-Cable for your cable size. Turn knob (#18) clockwise
(right) until contact is made with drive bearing.
7. Installation is complete. Refer to operating instructions for safe operation.
