Page 24
Item No Part No Req'd Description
13 04204700 1 Lower Casting Assy (Includes Items 9, 10, 11, 25, 26, 27)
14 02994400 2 Screw, HX Hd 5/8-18 x 4
15 02820800 2 Nut, Hex Jam 5/8-18
16 00167600 2 Lockwasher, 5/8
17 02897800 2 Rubber Tired Wheel 8 x 2.50
18 00114800 1 Screw, Hx Hd 5/16-18 x 5/8
19 00165600 1 Lockwasher, Kantlink
21 04205100 1 Outer Drum and Cover Spinning Assy (Includes Item 24)
22 44063100 1 External Drum Assy (Includes Items 21, 28, 29, 45, 46)
23 02756900 1 Internal Drum Assy (Includes Flanged Bearing Rivited to Drum and Items
18, 19, 47)
24 44110600 1 1065 Cable Clamp Assy
25 02821100 4 Nut, Hex 3/8-24
26 00167200 4 Washer, 3/8 Internal Tooth Lock
27 02826500 4 Screw, Hex Hd 3/8-16 x 1-1/4
28 04205200 1 Outer Drum Hub and Bearing Assy
29 02769100 1 Thrust Bearing
30 04205500 2 Crawler Tread Assy (Includes Items 31, 32, 33 and belt)
31 00118900 4 Hex Head Cap Screw 1/2-13 x 2-1/2
32 00167400 4 Washer, Lock- Internal Tooth
33 00778000 4 Nut, Hex 1/2-13 Zn Plt.
35 00116000 2 Screw, Hx Hd Cap 3/8-16 x 1/2
36 00140000 2 Square Nut, 3/8-16 Zn Pltd
37 04205400 1 Back Casting Assy (Includes Items 25, 26, 27, 31, 32, 33, 41, 53)
38 44292400 1 .66 Anchor Cable (Includes Item 44)
40 04205300 1 Tangent Lock Assy
41 02853800 2 Thumb Screw, 3/8-16 x 1-1/2
43 44292300 1 Motor Cover Assy (Includes Mounting Screws and Washers)
44 44291501 1 .66-3/4" Anchor Adapter
45 00114800 12 Screw, Hx Hd 5/16-18 x 5/8
46 02825000 12 Int/Ext Tooth Lockwasher
47 02796300 1 Grease Zerk, 1/8" IPT 45 deg
48 02750200 1 Drum W asher
49 02822300 1 Thumb Screw, 3/8-16 x 3/4
51 03410500 2 Adjustable Knob
52 02796200 1 Grease Fitting
54 03411400 1 Distributor Arm Bearing Assy For Use W ith Power Cable Feed (Includes
Swing Bolts, Adj Knobs, Grease Fitting)
55 03409800 1 Thrust Bearing
56 04221000 1 Model 75 Power Feed
57 44280700 1 Cord Wrap
58 02824000 2 Screw Slotted Rd Head
59 03850100 2 Hex Nut #10-32
60 44291100 1 Motor Support Complete
61 44282500 Decal Package Complete 1065
62 03444500 1 Distributor Arm Assembly
63 44225300 1 Cable Guide Assembly
Model 1065
Final Assembly 44115804
