Spartan 1065 - Page 43

Page 43
Power Cable Feed Section
Table of Contents
Introduction --------------------------------------- 44
Attaching the Cable Safety Guide ----------- 45
Setting Your Cable Size ----------------------- 46
04221000 Universal Power Feed ----------47
04217500 Power Feed Assembly ----------- 48
04224000 Bearing Block Assy (Long) ----- 49
44219900 Bearing Block Assy (Short) ----- 50
44119600 Wheel Carrier Body (Long)----- 44
44119700 Wheel Carrier Body (Short) ----- 44
Model 1065 & 2001 Installation -------------45
Model 200 and 300 Installation ------------- 46
Model 100 Installation ------------------------- 47
Operating Instructions ------------------------- 48
Cleaning Operation ----------------------------- 49
Disassemble & Reassemble Power Feed 49
Disassembly of Short Bearing Blocks ------ 50
Disassembly of Long Bearing Blocks ------ 51
Cleaning & Lubricating Instructions --------- 52
Re-Assembly of Short Bearing Blocks ----- 52
Re-Assembly of Long Bearing Blocks ------ 53
Cable Safety Guide Instructions--------- 54-55
