Specialized CHISEL - Bearing and Spacer Specifications

10
4.3. BEARING AND SPACER SPECIFICATIONS
LOCATION QTY DIMENSION INFO
1 Main Pivot Bearing (Chainstay) 2 12 mm ID x 24 mm OD x 6 mm W, DBL SLD 6901V-2RS
2 Main Pivot Spacer 2 12.1 mm ID x 19.5 mm OD x 3 mm W Tapered edge against the bearing
3 Link Bearings 6 10 mm ID x 19 mm OD x 5 mm W, DBL SLD 6800V-2RS
4 Link at Seat Tube Spacer 2 10.1 mm ID x 16.5 mm OD x 2 mm W
5 Link at Extension/Seatstay Spacer 8 Custom, 8 mm ID x 16.5 mm OD x 2.5 mm W
