Specialized CHISEL - Bolt, Axle, Washer, and Flip Chip Specifications

12
4.4. BOLT, AXLE, WASHER, AND FLIP CHIP SPECIFICATIONS
LOCATION QTY DIMENSION TOOL SIZE
TORQUE
Nm in-lbf
1
Main Pivot Bolt 1 M8 x 12.2 mm x 1 mm P 5 mm hex 10 89
2 Main Pivot Axle 1 M10 Threaded Axle
3
Link at Seat Tube Bolt 2 M10 x 16 mm x 1 mm P 6 mm hex 10 89
4
Link at Seatstay & Extension Pivot Axle 4 M5 Threaded Axle 4 mm hex 6 53
5 Link at Seatstay & Extension Pivot Bolt 4 M5 x 8 mm x 0.8 mm P 4 mm hex 6 53
6 Rear Shock Mounting Bolt 1 M8 x 26 mm x 1.25 mm P 6 mm hex 20 177
7
Rear Shock Mounting Washer 1 M8, 8.4 mm ID x 13 mm OD x 0.5 mm THK
8
Flip Chip 2 8 mm ID x 15 mm OD x 6.5 mm W - GEO ADJ
9 Forward Shock Mounting Bolt 1 M5 x 8 mm x 0.8 mm P 4 mm hex 6 53
10 Forward Shock Mounting Axle 1 M5 Threaded Axle 4 mm hex 6 53
11
Forward Shock Mounting Washer 2 M8 x 8.25 ID x 15 OD x 0.3 THK
