Specialized CHISEL - Rear Brake (Red); Mechanical Rear Derailleur (Green); Dropper Post (Blue); Head Tube ICR Port

26
The housings and hose must be installed without the fork installed
in the frame.
6.1. REAR BRAKE (RED)
 Starting at the exit port on the inside surface of the non-drive side of the
chainstay, route the hose through the chainstay until it exits the nylon
guide tube at the chainstay bridge.
 Guide the hose up the down tube until it exits the head tube, then slide a
Churro (foam tube) onto the hose.
 Once the Churro is installed, guide the hose back down into the down
tube, then guide the hose out the port on the non-drive side of the head
tube.
6.2. MECHANICAL REAR DERAILLEUR (GREEN)
 Starting at the exit port in front of and below the drive side dropout, route
the housing through the chainstay until it exits the nylon guide tube at the
chainstay bridge.
 Guide the housing through the ICR funnel and up the down tube until it
exits the head tube, then slide a “Churro” foam tube onto the housing.
 Once the Churro is installed, guide the housing back down into the down
tube, then guide the housing out the port on the non-drive side of the
head tube.
6.3. DROPPER POST (BLUE)
Before routing the housing, remove the bottom bracket so you can
access the housing to help route it past the bottom bracket ICR
funnel up the seat tube.
The dropper housing is easiest to route after the brake hose and
derailleur housing.
 Starting at the head tube, route the housing down the down tube and up
the seat tube until it exits the seat tube.
 S lide a “Churro” foam tube onto the housing and route it into the down
tube.
 Once the Churro is installed, guide the housing back down into the down
tube, then guide the housing out the port on the drive side of the head
tube.
6.4. HEAD TUBE ICR PORT
 Slide the non-drive side ICR port over the shift housing and brake hose
then assemble it to the frame. Using a 2.5 mm hex key, tighten the bolt
to 2 Nm / 18 in-lbf.
 Slide the drive side ICR port over the dropper housing and assemble it
to the frame. Using a 2.5 mm hex key tighten the bolt to 2 Nm / 18 in-lbf.
For easier installation of the ICR port, thread the ICR port bolt
into the frame a few turns, then flex the plastic port over the bolt
before tightening.
