4.1. GENERAL SPECIFICATIONS
PART DESCRIPTION PART # TOOL SIZE
TORQUE
Nm in-lbf
1 Front Triangle
2 Rear Triangle S221500006
3 Fork
4 Seatpost 30.9 mm Diameter
5 Saddle
6
BB Cable
Guide Funnel
A: Funnel
S226500012
B: Bolt
M4 x 0.7 mm x 8 mm 2.5 mm hex 1.5 13
7
Bottom Bracket 73 mm (BSA threaded)
8
Mudguard Double Sided Adhesive Tape S246900004
9
Shock Link See Suspension Specification S204300002
10
Shock Extension See Suspension Specification S206300001
11
Brake Mount
A: Brake Mount
160 mm Rotor
S220700005
B: Brake Mount Bolt
M6 x 20 mm x 1.0 mm P 5 mm hex 6 53
C: Brake Mount Washer
M6 x 6.4 mm ID x 10 OD x 1 mm THICK
12
Headset
A: Top Cover
1-1/8"
S182500004
B: Compression Ring
28.8 mm DIA
C: Upper Bearing
1-1/8"-41.8 mm OD x 30.5 mm ID x 6.5 mm (45�x 45�) S092500001
D: Upper Bearing Cup
Zero Stack Press-Fit for 1-1/8" bearing (44 mm DIA)
E: Lower Bearing Cup
Zero Stack Press-Fit for 1.5" bearing (55.99 mm DIA)
F: Lower Bearing
1.5"-52 mm OD x 40 mm ID x 7 mm Thick (45�x 45�) S222500012
G: Crown Race
39.76 mm DIA
13 Headset Spacer 1-1/8" 28.6 mm ID x 5 mm THICK
