Specialized CHISEL - Page 9

7
14 ICR Port
A: Drive Side Port
Single 5 mm
S206500013
B: Non Drive Side Port
Double 5/5 mm
C: Bolt
M4 x 0.7 mm P x 8 mm 2.5 mm hex 2 18
15 Top Cap 1-1/8" S142500002 4 mm hex
16
Seatpost Clamp 34.9 mm Diameter S184700003 4 mm hex 6.2 55
17
Stem
A: Faceplate Bolts
4 mm hex 6 53
B: Steerer Bolts
4 mm hex 6 53
18 Handlebar
19 Derailleur Hanger SRAM UDH Derailleur Hanger S202600002 8 mm hex 25 221
20 Rear Thru Axle 148 mm Spacing, 172 mm Length, 12 mm S170200003 6 mm hex 15 133
21 Front Thru Axle
22 Chainstay Protector S246900005
COMPONENT COMPATIBLE SIZES/SPECS COMPONENT COMPATIBLE SIZES/SPECS
Headset Upper Bearing
1-1/8" 41.8 mm OD x 30.5 mm ID x 6.5 mm (45� x 45�)
Min / Max Front Rotor
160 mm / 180 mm (fork manufacturer’s guidelines)
Headset Lower Bearing
1.5" 52 mm OD x 40 mm ID x 7 mm (45� x 45�)
Min / Max Rear Rotor
160 mm / 180 mm with custom Chisel adapter
Bottom Bracket Shell
73 mm (BSA threaded)
Rear Hub Spacing
Boost 148
Max Rear Tire
29 x 2.4 in
Front Hub Spacing
Boost 110
Rear Wheel Travel
120 mm
Chainring OE Spec
32 t
Shock Length / Stroke
190 mm / 40 mm
Min Chainring
30 t
Recommended Shock Sag
11 - 12 mm (27 - 30%)
Max Chainring
34 t (52 mm chainline) / 36 t (55 mm chainline)
Min/Max Fork travel
120 mm / 130 mm (evo)
Min / Max Front Chainline
52 mm / 55 mm
Bottle clearance
2 bottles (size XS only 1 bottle)
Optional Chain Guide
S2211200002
