Specialized CHISEL - Page 6

4
GEOMETRY
FRAME SIZE
XS S M L XL
A Stack (mm) 602.3 593 606 620 629
B Reach (mm) 390 415 445 470 495
C Head tube length (mm) 95 95 110 125 135
D Head tube angle (°) 66.5° 66.5° 66.5° 66.5° 66.5°
E
BB height low (mm) 326 336 336 336 336
BB height high (mm) 332 342 342 342 342
F
BB drop low (mm) 46 36 36 36 36
G Trail (mm) 113 113 113 113 113
H Fork length: full (mm) 530 530 530 530 530
I Fork rake offset (mm) 44 44 44 44 44
J Front center (mm) 682 706 742 773 802
K
Chainstay length (mm) 437 437 437 437 437
L Wheelbase (mm) 1115 1141 1177 1208 1237
M
Standover height (mm) 756 777 777 787 790
N Seat tube length (mm) 375 392 410 450 500
O
Seat tube angle (°) 75.5° 75.5° 75.5° 75.2° 75°
P Top tube length, horizontal (mm) 527 565 602 634 664
Crank length (mm) 165 170 170 175 175
Handlebar width (mm) 760 760 760 760 760
Stem length (mm) 60 60 60 60 60
Saddle width (mm) 155 155 143 143 143
All models come standard with the extension flip chip in the low position.
