Spectra SAM-3040D - Page 11

11
Introduction
AMT
Rear Panel I/O
Ports
I/O Connector
BIOS
Energy Efficient
Design
Damage Free
Intelligence
Temperature
Humidity
PCB
•SupportsiAMT6.0
•Out-of-bandsystemaccess
•Remotetroubleshootingandrecovery
•Hardware-basedagentpresencechecking
•Proactivealerting
•Remotehardwareandsoftwareassettracking
•1Mini-DIN-6PS/2mouseport
•1Mini-DIN-6PS/2keyboardport
•2DB-9serialports
•1DB-15VGAport
•1DVI-Iport(DVI-Dsignalonly)
•4USB2.0/1.1ports
•2RJ45LANports
•Mic-in,line-inandlineoutjacks
•4connectorsfor8additionalexternalUSB2.0/1.1ports
•2connectorsfor2externalserialports
•1LVDSLCDpanelconnector
•1LCD/inverterpowerconnector
•1DigitalI/Oconnector
•1frontaudioconnectorforline-outandmic-injacks
•1CD-ininternalaudioconnector
•1S/PDIFconnector
•4SerialATAconnectors
•144-pinIDEconnector
•124-pinATXpowerconnector
•1frontpanelconnector
•2fanconnectors
•AMIBIOS
•64MbitSPIBIOS
•SupportsACPIspecificationandOSDirectedPowerManagement
•SupportsACPISTR(SuspendtoRAM)function
•Wake-On-Eventsinclude:
- Wake-On-PS/2 KB/Mouse and Wake-On-USB KB/Mouse
- Wake-On-LAN and Wake-On-Ring
- RTC timer to power-on the system
•Systempowermanagementsupported
•CPUstoppedclockcontrol
•Microsoft
®
/Intel
®
APM 1.2 compliant
•SoftPowersupported-ACPIv2.0specification
•ACpowerfailurerecovery
•MonitorsCPU/Systemtemperatureandoverheatalarm
•Monitors Vcore/5V/1.05V/1.5V/12V/3.3V/3.3VSB/VBAT
voltages and failure alarm
•MonitorsCPU/Chassis/1stfanfanspeedandfailurealarm
•Readback capabilitythatdisplaystemperature,voltageand
fan speed
•Watchdogtimerfunction
•0
o
C to 60
o
C
•10%to90%
•Mini-ITXformfactor
•17cm(6.7”)x17cm(6.7”)
