Spectra SAM-3040D - Chapter 1 - Introduction; Specifications

1
10
Introduction
Processor
Chipset
System Memory
Expansion Slots
Graphics
Audio
LAN
Serial ATA
IDE
Chapter 1 - Introduction
•Intel
®
Core
TM
i7-620M (SV)
Intel
®
Core
TM
i5-520M (SV)
Intel
®
Celeron
®
P4500 (SV)
•SupportsIMVP6.5upto35WCPU
•Processorsocket:SocketGrPGA988A
•Intel
®
QM57IbexPeak-MPCH(PlatformControllerHub)
•Two204-pinSODIMMsockets
•Supports800/1066MHzDDR3SDRAM(PC3-6400/PC3-8500)
•Dualchannelmemoryinterface
•Supportsmaximumof8GBsystemmemory
•DRAMdevicetechnologies:1GBand2GBDDR3DRAMtech-
nologiesforx8andx16devices,unbuffered,non-ECC
•1PCIExpressx1slot
•1PCIslot
•Intel
®
Gen5.75integratedgraphicsengine
•Displayports:DVI-I(CH7318),LVDSandVGA
•Intel
®
ClearVideotechnology
•Intel
®
DynamicVideoMemoryTechnology(Intel
®
DVMT)
•Intel
®
Smart2DDisplayTechnology(Intel
®
S2DDT)
•RealtekALC2622-channelHighDefinitionAudio
•HighperformanceDACswith100dBSNR
•ADCswith90dBSNR
•Two stereo DACs support 24-bit PCM format for stereo au-
dioplayback
•Three stereo ADCs support 20-bit PCM format for multiple
inputstreaming
•S/PDIFinput/outputinterface
•Intel82577LMwithiAMT6.0GigabitLANPhy
•RealtekRTL8111CPCIExpressGigabitcontrollers
•Integrated10/100/1000transceiver
•FullycompliantwithIEEE802.3,IEEE802.3u,IEEE802.3ab
•Supportswiremanagement
•4SerialATAports
•Datatransferrateupto3Gb/s
•Integrated Advanced Host Controller Interface (AHCI) control-
ler
•SupportsRAID0,RAID1,RAID5andRAID10
•JMicronJMB368PCIExpresstoPATAhostcontroller
•DMAmode:UltraATAupto100MB/s
•PIOmode:upto16MB/s
Specifications
