Spectra SAM-3040D - RJ45 LAN Port

37
Hardware Installation
RJ45 LAN Ports
The LAN ports allow the system board to connect to a local area network by
meansofanetworkhub.
BIOS Setting
Congure the onboard LAN ports in the Chipset menu (“South Bridge submenu)
oftheBIOS.Refertochapter3formoreinformation.
Driver Installation
InstalltheLANdrivers.Refertochapter4formoreinformation.
LAN1
(Intel)
LAN2
(Realtek)
