Hardware Installation
Wake-On-USB Keyboard/Mouse
TheWake-On-USBKeyboard/MousefunctionallowsyoutouseaUSBkeyboardor
USBmousetowakeupasystemfromtheS3(STR-SuspendToRAM)state.To
usethisfunction:
• JumperSetting
 JP2mustbesetto“2-3On:5V_standby”.Referto“USBPowerSelect”inthis
chapterformoreinformation.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB
ports, the 5V_standby power source of your power supply must support
≥1.5A. For 3 or more USB ports, the 5V_standby power source of your
powersupplymustsupport≥2A.
