XML File Description
sip.dnsmethod = dnssrv
Set the DNS method used to resolve the SIP
server.
Values:
“arecord”: Use DNS A records only.
“dnssrv”: Use DNS SRV records and A records.
Default: arecord.
Recommended setting for BroadWorks: dnssrv.
4.2.3 Configure Service Settings
XML File Tag Description
feature_codes.enable = true
To activate the call forward feature, the setting
needs to be enabled. On Handset activated via
feature code: *21*[forwarding number]#.
Disabled on handset via #21#.
4.3 Subscriber Level Configuration
This section identifies the device-specific parameters, including registration and
authentication. These settings must be unique across devices to be matched with the
settings for a BroadWorks SIP trunk or subscriber. SIP Registration requires that a unique
address of record (AoR) is provisioned on BroadWorks and the device.
XML file tag Description
user.username = 123456
The register user ID must correspond with the
line/port setting on BroadWorks.
user.authuser = SpectralinkUser1
user.authpassword = Spectralink01
If the Authentication service is configured on
BroadWorks, these parameters must be
configured to match the BroadWorks settings.
Note that the password can be saved as hashed
value as well.
user.displayname = User 1
The name to be displayed (caller ID) at other SIP
devices, for example, User 1 in User
1<1234566@somecompany.com.
user.standbytext = 123456 User 1
Configure the text to be displayed on the device.
4.4 SIP Advanced Feature Configuration
This section provides configuration instructions for advanced SIP features supported by
the phone including but not limited to Shared Call Appearance, Busy Lamp Field, Feature
Key Synchronization, Call Center, Emergency Call, Advice of Charge, Call Recording, and
Security Classification.
4.4.1 Shared Call Appearance Configuration
Not Supported.
