19SPEKTRUM DX10t • RADIO INSTRUCTION MANUAL
EN
9-10 Mixer
The DX 10t offers 8 mixes for helicopter. You can program
a mix Cyclic > Throttle that is active at Aileron, Elevator
and Rudder. This mix avoids RPM decay with rudder
movement.
The Swashplate mix mixes Aileron to Elevator and
Elevator to Aileron for a better timing of the Swashplate.
There are 6 programmable mixes available. You can
activate mixes with Flight Modes and the Gear switch.
The programmable Mixes have an Offset function where
mixer interceptions can be selected as slave trimming
from Master to Slave Channel.
Programming the Mixer
Press the roller from the Main or Telemetry display to
access the Function List.
Cyclic to Throttle mix
Cyclic to Throttle Mix prevents rpm decay when aileron,
elevator and/or rudder inputs are given.
At full throttle, programming prevents the throttle from
overdriving the servo.
When using a Governor, Cyclic to Throttle mix is not
recommended.
Assigning Cyclic Mix to a Flight Mode(s)
Rotate the Roller to highlight the desired box at the
bottom of the screen. Press the Roller to darken the box
and activate Cyclic Mix in that Flight Mode position. You
can highlight more than one Flight Mode position. If all
boxes are highlighted, the
C-Mix function is always on. If no boxes are highlighted,
the function is always off.
Adjusting Cyclic Mix Rates
Rotate the Roller to highlight the desired rate then press.
Rotate the Roller to adjust
the value. The available positive + and negative - values
reverse the direction of the throttle mix.
Adjust the rates for all desired channels.
9-11 Range Test
Please refer to wing-type model programming for
instructions.
9-12 Timer
Please refer to wing-type model programming for
instructions.
9-13 Telemetry
Please refer to wing-type model programming for
instructions.
9-14 Servo Monitor
Gives you information about the servo position.
