Unpacking Generator:
In addition to the XRV Generator, there will be several accessories. The 4kw unipolar models include a
CD/DVD program setup, Interlock bypass subminiature D connector and a Main Power Connector. The
6kW unipolar generator includes an additional Auxiliary Power Connector. The 4kW bipolar generator
includes an interconnect power cable and 2 additional subminiature D cables for the feedback and
inverter control for the additional positive polarity generator. Additional subsystem components such as
the X-ray tube, Cooler/Chiller
P/N 105808-434 Conn.
P/N 105808-440 Clamp
P/N 105808-654 (4) Pin Conn. (6kW)
P/N 105808-440 Clamp
P/N 105808-441 (3) Pin Conn. (6Kw)
P/N 105808-440 Clamp
P/N 203373-001 25 Pin
Subminiature D
P/N SWD0026-009
Software
P/N 304747-001
(Bipolar XRV Only)
P/N PNC4002A
(Bipolar XRV Only)
P/N PNC4002A
(Bipolar XRV Only)
