Page 65 of 98
118157-001 Rev C
Power Source Connections (Unipolar Basic):
The circuit breakers should be located on a panel in an accessible area. It is recommended but not
necessary to have an emergency stop switch that will interrupt all the input power sources to the
generator and subsystem.
Verify that the ground buss bar in the main breaker panel connects to earth ground. Connect the mains
and auxiliary cable from the XRV generator and the cooler or chiller to the load side of the circuit
breakers.
Breaker Box
