Spheros Thermo E 320 - Wiring Diagrams; General

Thermo E 200 / 320 6 Wiring diagrams
601
6Wiring diagrams
6.1 General
The following figures represent heater connection options
to the vehicle electrical system.
The in the table below shown cable cross-sections are to
be used.
Cable length <7.5m Cable length 7.5 - 15m
0.75 mm² 1.5 mm²
2.5 mm² 4.0 mm²
