Operation manual – Spider MINI
23 / 53 rev. 02-01-10-2011
8.3. CHECKING ENGINE OIL LEVEL
ATTENTION! Before checking or refilling engine oil stop the engine and let it cool down.
The oil level of the machine standing on a level surface must be between the limit marks on the dipstick (see
the engine user’s manual). Check oil according to the engine user’s manual as follows:
Place the machine on a level surface.
Remove the upper cover of the mower. Unscrew the oil cap and clean the dipstick.
Put the dipstick back into the filler, tighten it and remove it again.
Check the oil level. If the oil level is close to or under the lower limit mark fill the engine with
recommended oil up to the upper limit mark.
Screw the cap with the dipstick back and tighten it.
Running the engine with insufficient oil may cause serious damage to the engine.
Check the engine oil level on a level surface and only when the engine is off. Use only oil
recommended by the engine manufacturer.
