Operation manual – Spider MINI
24 / 53 rev. 02-01-10-2011
8.4. HYDRAULIC SYSTEM OIL
The hydraulic system of the mower is closed and daily checks of oil level are not necessary. However the
operator must check the tightness of all components of the hydraulic system. In case of oil leakage caused by
the damage to the hydraulic system, have the mower serviced and oil refilled by an authorized service dealer.
8.5. PREPARING THE BATTERY
SPIDER MINI mower uses a gel battery type GiV, 12 V, 18 Ah
Do not fill the battery with electrolyte. The machine construction uses a dry type of battery. If
recharging, use a maximum electric current of 1.4 A.
.
Loosen bolt (A) and open the battery cover.
Insert the battery
Attach back the battery cover.
Attach terminal connectors according to polarity: first (+) then (-).
When disconnecting the battery, work in reversed order. First disconnect (-) then (+) battery pole.
Never start the mower when a charger is connected to the battery. FOR CHARGING USE ONLY
SPECIAL CHARGERS PREVENTING THE EXCESS OF GASSING VOLTAGE.WHEN CHARGING
THE BATTERY MAKE SURE THAT CABLES CONNECTING THE BATTERY TO THE MOWER ARE
DISCONNECTED.
It is strictly prohibited to dis-/connect the battery while the engine is running.
