Operation manual – Spider MINI
37 / 53 rev. 02-01-10-2011
10.5. VERTICAL SERVICE POSITION
For cleaning and maintenance of the mower deck it is possible to place the mower to a vertical service position.
The vertical service position may only be used on a firm and flat surface and only for the time needed to perform
the maintenance.
It is prohibited to leave the mower in the vertical service position unattended or to store it this way.
It is prohibited to manipulate with the height adjustment lever while the mower is in the vertical
service position.
Instructions:
1. Place the mower on a flat and firm surface.
2. Turn the wheels so that the tyres are next to the hydraulic tank.
3. Turn the mower off by the EMERGENCY STOP button.
4. Check the tightening of the fuel cap and the engine oil dipstick.
5. Close the fuel cock.
6. Fold the bumpers to the upper (vertical) position.
7. Select minimum height of cut.
8. Use the handles on the exhaust side of the mower to lift it as far up until the handles on the hydraulic
tank side lean against the ground.
