Operation manual ā Spider MINI
30 / 53 rev. 02-01-10-2011
9.6. HEIGHT OF CUT ADJUSTMENT
The mower has 6 positions of cutting height adjustment. The height of cut can be adjusted within the range
of 40 to 90 mm (1,5 to 3,5 inch).
The height of cut can be adjusted by the height adjustment lever on the mower. The height of cut may only
be adjusted when the engine is shut off.
To change the height of cut hold the height adjustment lever in the current position, unlock the latch, move
the lever to the desired position and lock it by releasing the latch. Then release the height adjustment lever.
The height adjustment system of the mower is supported by a strong spring, which reduces the
power needed to change the height of cut. The height should only by adjusted when the mower
is standing on all four wheels. Other position of the mower may cause the height adjustment level
to shoot down when unlocked.
In areas with tall or wet growth use higher position of the mower deck.
Lowest height setup is used for the mowing of flat and well maintained areas.
If mowing an unknown area for the first time, it is recommended to select a higher position of
mower deck, mow the area and then repeatedly check the area for debris. Next mowing should
be performed after the mowed grass has dried.
The height of cut on a slope may significantly vary from that on a flat surface.
