98
6000 Bird Dog Plus Only
Secondary Current Cable
o A phase clamp-on CT or duckbill connector copper side up in line A (I
A
)
o C phase clamp-on CT or duckbill connector copper side up in line C (I
C
)
Form 5 4 Wire Delta ABC Rotation Form 5 4 Wire Delta CBA Rotation
Unity Power Factor Unity Power Factor
F.3.2.4 Form 6 Meter: 4 Wire Wye—The Form 6 meter has 3 current coils and 2
½ stators. It is a CT rated meter. It will require 1 test to determine the accuracy of the
meter. The hookup is as follows:
Automatic Phase Rotation Test—Voltage Cable Hookup
Red alligator clip—Phase A
White alligator clip—Neutral
Black alligator clip—Phase C
Yellow (or green for older units) alligator clip leave unconnected
Meter Test Hookup
Secondary Voltage Cable
o Red alligator clip to phase A
o White alligator clip to neutral
o Black alligator clip to phase C
o Yellow (or green for older units) alligator clip leave unconnected
Secondary Current Cable
o A phase clamp-on CT or duckbill connector copper side up phase A (I
A
)
o B phase clamp-on CT or duckbill connector copper side up phase B (I
B
)
o C phase clamp-on CT or duckbill connector copper side up phase C (I
C
)
Form 6 4 Wire Wye with ABC Rotation Form 6 4 Wire Wye with CBA Rotation
Unity Power Factor Unity Power Factor
