SECTION F.2.1
STANDARD TEST PROCEDURE FOR SINGLE ELEMENT
METER CIRCUIT TESTING ONLY
(Save ONLY the GLOB SAVE Screen—Forms 3, 4, 5, 6, 8, 9 Meter
Circuits)
1. Hookup Probes to Phase A (or B or C as appropriate)
1.1 Primary Current: Flex Coil--Arrow towards load, High Voltage--Large Dot
Toward Line
1.2 Secondary Current: Duckbill / Copper side up (If 6000 Bird Dog Plus owner,
use only phase A duckbill with the large knob on the 3 Phase Connector Box
set to Duckbills and the small knob set to either Flexible Coil or High
Voltage.)
1.3 Secondary Voltage: Alligator Clips /Red to phase A (or B or C), Black to phase
C (Connect to phase C on the lug above the switch & leave it there for the entire
test.), and white to neutral/low side. (If 6000 Bird Dog Plus owner, leave Yellow
(or green for older units) alligator clip unconnected.)
1.4 Confirm Proper Voltage Wiring from the Test Switch to the Meter
(Skip this section if using Meter Base Adapters.)
1.4.1 Short phase B & C CTs and confirm the meter is reporting phase A
1.4.2 Short phase A & C CTs and confirm the meter is reporting phase B
1.4.3 Short phase A & B CTs and confirm the meter is reporting phase C
1.4.4 Close all CT shorting switches
2. Turn the Bird Dog Plus On
3. Enter Meter/Circuit/Rotation
3.1 If listed data is the same as your circuit: press YES and go to 4.1
3.2 If listed data is different than your circuit: press NO, select correct data and go to 4.1
3.3 If your circuit is not known or irrelevant: press UNDEFINED and go to 4.1
4. Enter LOCATION CODE
4.1 FromLOCATION CODE screen press CHANGE button. Arrow points to
first digit
4.2 Press the CLEAR button
4.3 Cycle the far left button 0-9, A-Z+ until the desired digit appears
4.4 Press the MORE button
4.5 Press NXT DIGIT. Arrow advances to next digit. Takes you back to previous
screen
4.6 Repeat 4.3 through 4.6 until new location code entered
4.7 When the new location code is entered, press the MORE button twice
4.8 Press the SAVE to store new LOCATION CODE and go to the MAIN MENU
5. Review the WIRE VERIFY GRAPH & Run the RATIO/BURDEN TEST
5.1 Select WV GRAPH from the MAIN MENU—the bottom right button
5.2 Select PHASE A (or B or C)
5.3 Review the readings as follows:
