6.5.4 INPUT WATER METER sub-menu
INPUT
W/METER
Enables the feedwater meter (water meter) to be selected.
Only available if proportional control is selected.
INPUT
W/METER
%
Only available if a water meter is selected. Enables the
water meter to be scaled so that it reads 100% at the
maximum boiler output.
Example
If the maximum boiler capacity is 60% of the maximum on
the meter scale, enter '60%'.
Note: Grey tint indicates features only available under certain conditions.
ä
ä
ä
OUTPUT
DRIVE
OUTPUT
RETRANS
OUTPUT
POSITION
ä
OUTPUT
COMMS
6.5.5 OUTPUT sub-menu
Selects type of control, pump IN / OUT, valve drive, dead-band.
See DRIVE sub-menu.
See notes opposite.
SELECT, SET, CHECK and ADJUST 0/4-20 mA
retransmission signal.
See notes in Section 6.5.7.
Only available if OUTPUT / DRIVE / TYPE / 4-20 mA is
selected. SELECT, SET, CHECK and ADJUST 0 / 4-20 mA
signal to the positioner.
See notes in Section 6.5.8.
Sets Modbus address, baud rate, infra-red master / slave
configuration and verifes the number of units on the IR bus.
See notes in Section 6.5.9.
To Next Page
