SRAM RockShox SIDLuxe Select+ 2P User Manual

10
Exploded View- Lever Adjust
Exploded View- Lever Adjust
1. Limit screw
2. Lever
3. Outer cam bushing
4. Flat point screw
5. Eyelet (Ultimate shown)
6. Limit screw
7. Inner cam bushing
8. Lever lock cam (2p)
9. Lever lock cam (3p)
10. Detent slider
11. Detent spring
12. Detent post
1
2
3
4
5
6
7
8
9
10
11
12
