Lever Installation
Lever Installation
The procedure for 2P and 3P lever installation are the same. The 2P and 3P lever lock cams and valve cups are not interechangeable and require
unique parts. Consult the RockShox Spare Parts Catalog at www.sram.com/service for parts.
NOTICE
To change from a 2P to a 3P control/damper system, or vice versa, requires a different valve cup and new lever or remote cams. See the
Lever and Remote Damper Change and Mid-Tune Valve Cup Change.
Install the inner cam bushing onto the lever lock cam.
Install the detent spring onto the detent slider and detent post.
Install the detent slider/spring/detent post assembly onto the lever lock
cam.
Apply grease to the spring. Install the assembly into the backside of the
eyelet.
Press and hold the detent post in the eyelet so the eyelet hole and
detent post hole align.
Install the limit screw and tighten until flush with the eyelet.
Install the outer cam bushing onto the frontside of the eyelet.
Grease
1
2
1.5 mm
3
