SRAM RockShox SIDLuxe Select+ 2P User Manual

38
Piston Service
200 Hour Service Piston Service
Clamp the shaft eyelet into the vise. Clamp the shaft eyelet into the vise.
NOTICE
Remote shocks: To prevent damage to the shock, use aluminium soft
jaws and position the eyelet in the vise so that the remote cable stop
and lockout pulley are clear of the vise jaws.
Move the seal head/air piston assembly down.
Use the piston tool and a 14 mm socket to remove the valve cup. Set
the valve cup aside.
Remove the valve slider and compression poker assembly from the
piston assembly.
1
2
Piston Tool
Piston Tool and 14 mm Socket Valve Cup
3
