SRAM RockShox SIDLuxe Select+ 2P User Manual

39
Piston Service
Loosen the piston bolt, then remove the piston assembly.
Be sure to keep the main piston assembly parts in the same order.
NOTICE
Keep all the parts together and set them aside. If changing the main
piston tune, consult the RockShox Rear Shock Piston Tuning Guide at
www.sram.com/service.
Remove the seal head/air piston.Remove the seal head/air piston.
Remove the bottom out bumper and the bottom out washer from the Remove the bottom out bumper and the bottom out washer from the
damper shaft.damper shaft.
Piston Tool Piston Tool and 14 mm Socket
4
5
6
