SRAM RockShox SIDLuxe Select+ 2P - Exploded View- Backside Remote

12
Exploded View- Backside Remote
Exploded View- Backside Remote
1. Limit screw
2. Remote cable pulley
3. Cam bushing
4. Limit screw
5. Cable hanger backside
6. Eyelet (Ultimate shown)
7. Cam limit screw
8. Preloader
9. Torsion spring
10. Lock cam 2P
11. Lock cam 3P
12. Inner cam bushing
13. Cam bushing
1
2
3
4
5
6
7
8
9
10
11
12
13
